DWOS™ Custom Abutments & SSRB



Abutments & Screw-Retained Bars & Bridges (SRBB)

DWOS™ Abutments & SRBB manages the design of custom abutments, implant bars and full virtual wax-ups for screw-retained bars and bridges (SRBB), while giving access to a wide range of implant systems. The design of all morphological elements of the prosthesis is fully integrated: the software automatically generates an anatomy to fit the custom abutment.

Implant Custom Abutments

DWOS™ ensures full control of the abutment’s critical parameters: emergence profile, clinical aspect, abutment screw opening and screw channel extension.

The automatic management of parallel axes ensures perfect insertion of the bridge over abutments. Screw-retained bridges can be designed using the same easy approach as a regular bridge combining pontics with custom abutments.

Access To A Wide Range Of Implant Systems

Our implant library contains an extensive range of implant systems that allows direct design of customized abutments as well as abutments on titanium bases. Additionally, users have the flexibility to create their own implant libraries.

Advanced Bar Design

Regarding implant bar design, DWOS™ features advanced editing functions that bring highly precise custom results. When the scan of the model has been performed by one of our scanners (3Series or7Series), the software delivers a certificate that guarantees the precision.

• Several types of implant bar designs are available, including: round, Dolder, Hader and milled


• The bar axis is set interactively


• The bar adjusts to fit the gingiva anatomically


• Bar pillars can be adjusted in height and angulation in relation to implant axis


• Each bar segment can be set to a different profile


• Extensions can be created


• Implant bar segments can be either on parallel plans or totally unconstrained



Fully Virtual Wax-Ups For SRBB

Our workflow eliminates the arduous need of handcrafting a wax-up. From the scan file with implant locators, the application suggests a full arch wax-up and its corresponding soft tissue. The final result can be a full contour screw-retained bridge or a framework of reduced anatomies.

The elements of the prosthesis (occlusal table, gingiva line and insertion axis) can be easily adjusted. The anterior and posterior sectors can be moved as independent entities for more efficiency.
